CMS external flow drum grille machine
product description
CMS external-inflow rotary drum grid machine (also known as external-inflow rotary drum microfilter) is a fine grid that can continuously and effectively remove suspended solids in water. Under certain grid gap conditions, it passes through The filtered sewage can remove 30% to 60% of organic matter and inorganic suspended solids. Scope of application Mainly used in the fine filtration of sewage pretreatment and industrial screening process, which can greatly reduce the processing load of the subsequent process. Outstanding advantages 1. The equipment adopts wedge-shaped grid as the filter element, which has the advantages of being suitable for fluid to pass and not easy to block; 2. The equipment uses stainless steel grids, which can be used for screening and filtering high temperature and high concentration liquids; 3. The equipment adopts a drum-shaped design and a large filtering area, so when the same processing capacity is used, the structure is compact, the area is small, and the energy consumption is low; 4. The equipment cleans the clogged dirt in the grid through the recoil nozzle, and the start and stop of recoil can be automatically controlled or realized by manual control; 5. The equipment can automatically and continuously run, and can automatically discharge slag, with a high degree of automation; 6. The equipment adopts a fully enclosed design to prevent secondary pollution during operation; 7. The overall structure of the equipment is made of high-quality stainless steel, which has the characteristics of corrosion resistance; working principle During operation, sewage (or other raw water) is pumped from the inlet pipe (tank) into the inlet tank of the drum grille, distributed by the baffle plate (or water distribution pipe), and flows evenly to the front of the grille drum surface. And flow into the drum through the grid surface, and finally out of the drum from the bottom. The suspended matter in the sewage stays on the rotating drum surface, and as the drum surface rotates, it is sent from the water inlet end to the discharge end on the other side, and it is shoveled off by the discharge mechanism.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
